Bir Arap Atında Diffuz İntraoküler Melanositik Tümör

Altı yaşında, kır donlu bir Arap atında saptanan intraoküler melanositik tümör olgusuna ilgili morfolojik bulgular tanımlandı. Klinik, makroskobik ve mikroskobik muayenede tümörün tüm göz kompartımanlarına yayılmış olduğu ve gözün nazal ve dorsal alanlarında ise ekstra-skleral yayılım gösterdiği ortaya kondu. Mikroskobik olarak tümöral kitlenin sınırlarının tam olarak belirgin olmadığı, yuvarlak, poligonal ve mekik şekilli hücrelerden oluştuğu ve değişen derecelerde melanin pigmenti içerdiği tespit edildi. Kornea'da ülser, keratinizasyon, vaskülarizasyon ve nötrofilik keratitis ve pre-iridial fibrovasküler zar oluşumu gibi sekonder lezyonlara da rastlandı. Operasyonu takiben 12 ay içerisinde nüks, metastaz veya dermal melanom bulgularına rastlanmadı.

Kır donlu bir Arap atında diffuz intraoküler melanositik tümör morfolojik bulguları ile ortaya konulmuş, ekstraskleral invazyona rağmen enükleasyon ve ekzenterasyonla başarılı bir şekilde tedavi edilebildiği sonucuna varılmıştır.

An intraocular melanocytic tumor was described in the eye of a 6-year-old, gray coat Arabian horse. Clinical, microscopical and macroscopical examination revealed that the tumor showed invasion to all of the ocular compartments as well as to nasal and dorsal regions. Microscopically; the tumor was poorly delineated and consisted of round, polygonal and spindle cells with having a different amount of melanin content. Secondary ocular changes including corneal ulceration, fibrinous plug, keratinization, vascularization, neutrophilic keratitis and pre-iridial fibrovascular membrane were also detected. There was no evidence of recurrence, metastasis or dermal melanoma development within one year after the operation.

Overall, the present report showed that diffuse equine intraocular tumor with extrascleral invasion could be successfully treated surgically with complete enucleation and exenteration of the orbit.

Giriş

Equine ocular tumors consist of approximately 10% of all the equine tumors. Based on the anatomic location in the orbit, these tumors are sub-classified as adnexal/palpebral, conjunctival, corneal, scleral, and intraocular types[1]. Although primary intraocular tumors are rare in horses, equine intraocular melanocytic tumor (EIMT) is the most common intraocular tumor reported and it affects iris, ciliary body or the whole globe[1-3]. Similar to equine dermal melanomas, horses with gray coat are predisposed to intraocular melanocytic tumors[2,3]. Equine dermal melanomas affecting 80% of gray horses are located in the skin, commissure of lips and ventral to the anus. Metastasis to visceral organs rarely occurs, however, equine dermal melanomas are generally fatal[2].

There have been 21 reported cases of intraocular melanocytic tumor published in veterinary medical literature up to now[2,4-6]. As 47.62% of all the dermal melanomas Show also a course with intraocular melanocytic tumor (10 out of 21 cases), it was suspected the dermal melanomas are multicentric or metastatic[2,4-6].

The aim of this report was to present the morphological characteristics of intraocular melanocytic tumor in a gray Arabian horse.

Olgu Sunumu

A 6-year-old, male, gray Arabian horse was referred to Veterinary Teaching Hospital, Veterinary Medical School of Firat University. Anamnesis indicated that the horse had a visual deficit at the left eye and have been blind approximately for the past 10 weeks. There were central corneal ulceration and fibrinous plaque covering the corneal surface (Figure 1). The intraocular examination could not be performed as the anterior chamber was filled with the melanocytic mass and hemorrhage. With general (10% chloral hydrate, intravenously, at the dose of 8 g/100 kg) and, local infiltration anesthesia (Lidokain HCl, L-Anestin, Alke, 20 mg/ml), complete enucleation and exenteration were performed following the method as described earlier (7-9). Briefly, the two elliptical incisions were combined in lateral and medial angles of the eye and blunt dissections through conjunctiva were made. And, musculus retractor bulbi and optic nerve were incised and bulbus oculi and adnexal tissue were totally removed. After local and systemic antibiotic treatment for 7 days, the recovery was achieved uneventfuly.

The eye was routinely fixed in 10% formalin solution and dorsoventral excision was performed for the gross and histological examination. And the sample was processed in 4-mm paraffin embedded cassettes; 5 μm cuts were obtained and stained with hematoxylin and eosin for histology.

Grossly and microscopically; there was an unencapsulated and poorly defined boundaries of the tumor with the extrascleral invasion in nasal and dorsal regions (Figure 2). The whole globe including anterior chamber, posterior chamber, vitreous, iris and, dorsal and ventral orbital tissue were filled with the tumoral mass. There was an apparent scleral and extra-scleral (orbital) invasion of tumor cells (Figure 3) with the scleral rupture. The mass contained mixture of spindle and polygonal cell, and variable in cell size (Figure 4). There was multifocal necrosis in neoplastic tissue and randomly distributed melano-macrophages. Some of the tumor cells contained densely laden melanin. No mitotic figure was detected in high magnification examination. Secondary ocular changes including corneal ulceration, fibrinous plug, keratinization, vascularization, neutrophilic keratitis and pre-iridial fibrovascular membrane were also detected.

Tartışma

Ultraviolet radiation, chemical exposure, trauma or chronic irritation, co-existence of cutaneous and ocular melanomas, and genetic variables have been proposed as factors in the development of melanomas in humans and animals[10]. In a retrospective analysis of 52 clinically diagnosed EIMT, Arabian horse (13 of 52 horses; corresponding 25%) and gray coat color (43 of 52 horses; 82.69%) are the most frequently affected horses[2]. Consequently, the present report also highlights the predisposition of Arabian and gray color horses for EIMT.

The tumor was diagnosed as EIMT based on the presence of plump, heavily pigmented cells and polyhedral cells with round nuclei and prominent nucleoli and no sign of malignancy. Previous reports of ocular melanocytic tumor in horses described similar histological findings to that presented in this case report[1-6]. In earlier reports[2,4-6]; EIMT was reported in iris (in 9/21 cases), iris and ciliary body (in 5/21 cases), iris, ciliary body and choroid (in 3/21 cases), iris, ciliary body, choroid, sclera and orbit (in 2/21 cases) and partial involvement of iris or ciliary body in 2/21 cases.

As a result, the present report showed that diffuse equine intraocular melanocytic tumor with extrascleral invasion was successfully treated surgically with complete enucleation and exenteration of the orbit with no evidence of recurrence and metastasis.

References

1. Montgomery KW. Equine ocular neoplasia: A review. Equine Vet Educ 2014; 7: 372-380.
2. Labella AL, RE Hamor, Labelle P, et al. Equine ocular melanomas in white coat horses. Acrivet Equine Ophtalmology Symposium, University of Stirling, Stirling, Scotland. June 10-12, 2012. 3. Wilcock BP. Eye and ear. In: Maxie MG. (Editor). Jubb, Kennedy, and Palmer's Pathology of Domestic Animals. 6th Edition, Volume 1, Volume 1. 6th Edition, Sandiago: Academic Press, 2015: 482-500.
4. Barnett, KC, Platt H. Intraocular melanomata in the horse. Equine Vet J 1990; 22: Supp, 76-82.
5. Mathews, AG, Barry DR. Bilateral melanoma of iris in a horse. Equine Vet J 1987; 19: 358-360.
6. Murphy J, Young S. Intraocular melanoma in a horse. Vet Pathol 1979; 16: 539-542.
7. Akın F, Samsar E. Göz Hastalıkları. Ankara: Tamer Matbaacılık, 1999.
8. Aslanbey D, Candaş A. Veteriner Operasyon. Ankara: Medisan Yayınevi, 1994.
9. Pierce Jr. KE, Townsend WM. Surgery of the globe and orbit. In: Auer JA, Stick JA. (Editors). Equine Surgery. 4th Edition, Missouri: Elsevier Inc. St. Louis, 2012: 727-743.
10. McMullen RJ, Clode AB, Pandiri AKR, et al. Epibulbar melanoma in a foal. Vet Ophtalmol 2008; 11: 44-50.
